KSM IV Plus

user-friendly machinery , including oscillation
including pneumatic belt tension, including folding veneer edge sanding device

Technical data

Dimension of sanding belt

3000 x 150 mm

Driving motor

3 kW

Electrical connection

3 x 400 V, 50 Hz

Speed of sanding belt

22 m/ sec

Belt support

swivelling up to 45 degree

Lever quick-adjustment

with scale

Oscillation motor

0,18 kW

Sanding table

cast iron, 900 x 400 mm, with mitre stop,height adjustable by pedal

Table stroke

200 mm

Exhaust tubes

left and right side of machine, diameter 120 mm variable table for radius-sanding

Air supply

6 bars

Speed of stream in central exhaustion

minimum 20 m/ s

Dimensions of machine

approx. 2000 x 800 x 1200 mm

Weight

approx. 400 kg

Additional equipments KSM IV plus

Driving motor pole exchange

2,7/3,3 kW   v 11/22  m/s

Driving motor frequency inverter

3 kW           v  variable speed

Radius sanding roller with belt

diameter 40 / 80 / 120 / 150 mm

Moving device

steering and stop idlers

Power cable

5 m incl. CEE-plug

Exhaust tubes on both sides

tied in diameter 160 mm for connection in central dust exhaust
